Ore Dressing Equipment
Wet Pan Mill
Wet Pan Mill

Wet Pan Mill

Product use:
It is mainly used for separation of gold with mecury, very hot sale in Africa. easy maintenance and high return on investment, can be replaced of ball mill for grinding of various kinds of minerals.
Details

It is mainly used for separation of gold, but also can be used for grinding  of silver, lead, zinc, molybdenum, iron, copper, antimony, tungsten, tin and  other minerals with less investment, fast results, saving power, sturdiness and  durability, easy of maintenance and high return on investment. It is the  preferred production for alternative ball mill, is ideal for small and medium  enterprises ore dressing.

Utility design is aimed to produce a new type of pan mill that is light in  weight, low in cost, low in energy consumption, low in production noise, low in  steel consumption and high in productivity.

1. When inputting gold sand into  the rolling drum, the rollers compress the sand over and over into tiny  particles.
2. Please put in 5 kg mercury at first, the mercury can absorb the  gold or other metals.
3. At last, use a high-density red cloth to wrap  mercury up.
4. Then squeeze it, the mercury will be pressed out and pure gold  stayed.

5. As to the large capacity, we can use mercury shaking machine and mercury  steamer to replace the manual work.


Main technical parameter:

Model

Specification(mm)

Feeding size

Speed(r/min)

Power(kw)

Weight(t)

1600A

1600*500*200*500+20

Feeding size less than 3cm

20-22

37

14.5

1500A

1500*350*200*460+20

20-22

22

13.3

1500B

1500*350*150*460+20

20-22

22

12.3

1500C

1500*300*150*420+20

20-22

18.5

11.3

1400A

1400*250*150*350+20

16-18

18.5

8.5

1400B

1400*250*150*350+20

21-23

18.5

8.5

1350A

1350*250*150*350+20

16-18

18.5

8

1350B

1350*250*150*350+20

21-23

18.5

8

1300A

1300*250*150*350+20

16-18

15

7.5

1300B

1300*250*150*350+20

21-23

15

7.5

1200A

1200*220*80*270+20

17-19

7.5

5.5

1200B

1200*200*80*250+20

23-25

7.5

5.5

1100A

1100*200*80*250+20

17-19

7.5

5

1100B

1100*200*80*250+20

23-25

7.5

5

1000

1000*200*80*250+20

13-15

5.5

4.5




It is mainly used for separation of gold, but also can be used for grinding  of silver, lead, zinc, molybdenum, iron, copper, antimony, tungsten, tin and  other minerals with less investment, fast results, saving power, sturdiness and  durability, easy of maintenance and high return on investment. It is the  preferred production for alternative ball mill, is ideal for small and medium  enterprises ore dressing.

Utility design is aimed to produce a new type of pan mill that is light in  weight, low in cost, low in energy consumption, low in production noise, low in  steel consumption and high in productivity.

1. When inputting gold sand into  the rolling drum, the rollers compress the sand over and over into tiny  particles.
2. Please put in 5 kg mercury at first, the mercury can absorb the  gold or other metals.
3. At last, use a high-density red cloth to wrap  mercury up.
4. Then squeeze it, the mercury will be pressed out and pure gold  stayed.

5. As to the large capacity, we can use mercury shaking machine and mercury  steamer to replace the manual work.


Main technical parameter:

Model

Specification(mm)

Feeding size

Speed(r/min)

Power(kw)

Weight(t)

1600A

1600*500*200*500+20

Feeding size less than 3cm

20-22

37

14.5

1500A

1500*350*200*460+20

20-22

22

13.3

1500B

1500*350*150*460+20

20-22

22

12.3

1500C

1500*300*150*420+20

20-22

18.5

11.3

1400A

1400*250*150*350+20

16-18

18.5

8.5

1400B

1400*250*150*350+20

21-23

18.5

8.5

1350A

1350*250*150*350+20

16-18

18.5

8

1350B

1350*250*150*350+20

21-23

18.5

8

1300A

1300*250*150*350+20

16-18

15

7.5

1300B

1300*250*150*350+20

21-23

15

7.5

1200A

1200*220*80*270+20

17-19

7.5

5.5

1200B

1200*200*80*250+20

23-25

7.5

5.5

1100A

1100*200*80*250+20

17-19

7.5

5

1100B

1100*200*80*250+20

23-25

7.5

5

1000

1000*200*80*250+20

13-15

5.5

4.5
