Mining Grinding
Rod Mill
Rod Mill

Rod Mill

Product use:
Rod mill has certain options in grinding material, commonly used in the applications with good uniform and low-over size products, such as manual manufacturing sand system in hydraulic engineering , water-coal slurry making in particles chemical industry.
Details

Rod Mill

Introduction

Rod mill can achieve selective crushing,  commonly used in the industries, which require final product to be uniform size,  little over-crushed particle size, such as metal rock, quartz sand, albite,  potash feldspar, manual construct sand making, water-coal-slurry making  industry.


Basically, rod mill has the similar  structure with ball mill. The main difference is: the grinding medium of rod  mill is a long round rod, while the grinding medium of ball mill is ball. They  are also different in the grinding form of grinding medium. The crushing process  of rod mill is realized by line contact between rods. Thus the crushing is  selective, and then small ones. So, compared to ball mill, the fineness of final  products processed by rod mill is even.


Main Technical Parameters

Model

Cylinder

Effective

Volume

(m³)

Max. Rod

Loading

(t)

Speed

(r/min)

Capacity

t/h

Discharging

size

(mm)

Main  Motor

(KW)

Weight

(t)

Diameter

(mm)

Length

(mm)

MBS(Y)-1530

1500

3000

4.5

8

27

15-6

2.00.15

90

18

MBS(Y)-1532

1500

3200

4.8

8.5

27

16-6.5

2.00.15

90

19

MBS(Y)-1830

1830

3000

6.7

12

23.7

20-9

2.00.15

130

34.5

MBS(Y)-1832

1830

3200

7.2

12.5

23.7

22-10

2.00.15

130

36

MBS(Y)-2130

2100

3000

8.8

18

21.4

30-12

2.00.15

180

45

MBS(Y)-2132

2100

3200

9.6

18.5

21.4

32-12.8

2.00.15

180

47

MBS(Y)-2136

2100

3600

11

20

21.4

35-14

2.00.15

210

48.5

MBS(Y)-2230

2200

3000

10

20.5

19

34-13

2.00.15

210

50

MBS(Y)-2236

2200

3600

12

24

19

40-16

2.00.15

245

52

MBS(Y)-2430

2400

3000

12

24.5

19

40-17

2.00.15

245

53.5

MBS(Y)-2436

2400

3600

14

28

19

47-19

2.00.15

280

61

MBS(Y)-2730

2700

3000

15.5

35

18.4

55-21

2.00.15

380

72

MBS(Y)-2736

2700

3600

18

38

18.4

65-24

2.00.15

400

89

MBS(Y)-2740

2700

4000

20.6

39

18.4

80-28

2.00.15

400

95

MBS(Y)-3040

3000

4000

25.7

54

17

90-34

2.00.15

630

114

MBS(Y)-3230

3200

3000

21

44

16.4

73-28

2.00.15

500

116

MBS(Y)-3245

3200

4500

32

67

16.4

110-44

2.00.15

800

132

MBS(Y)-3642

3600

4200

38

79.5

15.8

120-50

2.00.15

1000

153

MBS(Y)-3645

3600

4500

40.8

85

15.8

140-56

2.00.15

1000-1250

168

MBS(Y)-3650

3600

5000

46

96

15.8

155-65

2.00.15

1250

176

MBS(Y)-3660

3600

6000

54

113

15.8

190-80

2.00.15

1400

198


Some spare parts of ball  mill



ball mill end  cap



girth gear



ball mill  cylinder



ball mill  liner



electric  system
