Ore Dressing Equipment
Spiral Chute
Spiral Chute

Spiral Chute

Product use:
Spiral chute is gravity separating device.It's suitable for separating different proportions non-ferrous metal,rare metal and non-metallic minerals.
Details


Spiral chute is gravity separating device.It's suitable for  separating different proportions non-ferrous metal,rare metal and non-metallic  minerals. such like: iron ore, gold ore, ilmenite,pyrites, zircon,  rutile,monazite,phosphorite,tungsten ore, tantalum, niobium and so  on.

Working principle:
Spiral Chute is working under  the force of water flow, gravity, inertial centrifuge and friction. Slurry is  pumped to the top of the spiral , and it enters a feed distributor that evenly  distributes the feed to each spiral concentrator. The design and shape of the  spiral make it work, when combined with gravitational acceleration. As the  slurry travels the spiraling path down the spiral, mineral grains settle and  start sorting according to size, density and to a lesser extend shape. Low  density particles are carried with the bulk of the water towards the outside of  the spiral , while particles with the greatest density migrate towards the  inside of the spiral.


Advantages and features:
Reasonable structure and small  occupation area
High recovery, high efficiency, and precise  separation
Non-required power
Light in weight, anti corrosion, rust and  wear resistant
Simple installation and Minimal maintenance  requirements

Technical parameters of spiral chute:


Model

diameter(mm

Pitch of  screw

Number of  threads

Number of  turns

Max.

Feed size (mm)

Mine density%

Capacity

t/h

Height

m

DI2000

2000

1200

24

3.5

0.044

2040

1545

6.8

DI1500

1500

900

24

4

0.030.3

2045

1025

6.1

DI1200

1200

720

540

24

45

0.030.3

3050

46

5.23

L900

900

540

360

23

45

0.030.3

3050

23

4

LI600

600

390

360

12

45

0.020.2

3050

0.812

2.6

LI400

400

180

12

45

0.020.2

3050

0.50.2

1.3
